Introduction

When you're upgrading your off-road rig with new suspension components or fresh wheels and tires, a proper alignment is essential. While it's best to have a professional shop handle alignments, there are situations where doing it yourself can help get you by, and that's what we want to talk about today.

In this guide, we'll walk you through performing a quick toe-in alignment using the tape measure method, specifically for straight-axle setups - check it out below and see how you can get your rig back up and running smoothly in a pinch!

When to Consider a DIY Alignment

If you've just installed new suspension parts, like an upgraded tie rod or drag link, or you’re simply driving an off-road rig that doesn’t need a perfect alignment because it spends most of its time on trails, this quick DIY method is for you. This guide focuses on toe-in alignment for vehicles with a straight axle, so we won’t be covering camber or caster adjustments - with that in mind, let's jump into the process.

Tools You’ll Need For A DIY Toe-In Alignment

To perform a DIY alignment in your garage, you don’t need much:

• Two straight edges (preferably metal, like aluminum angle iron pieces, to avoid warping).
• Two ratchet straps.
• A tape measure.
• A hammer (to adjust tabs on the Apex Chassis components).
• A crescent wrench (for tightening jam nuts).

Additionally, having an angle finder or level can help ensure your straight edges are properly aligned, though it's not necessary.

Step-by-Step Alignment Process

• Prepare the Vehicle and Tools: Attach the two straight edges to the outside of your front tires using ratchet straps. Make sure they are securely fastened and parallel to each other.
• Measure the Toe-In: With the straight edges in place, use a tape measure to measure the distance between the front of the tires and the rear. Be careful to avoid any obstacles like the driveshaft or control arms that might interfere with the tape measure, as even a slight angle or curve can affect your measurement.
• Set the Toe-In Alignment: Your goal is to achieve an eighth-inch toe-in, meaning the front of your tires should be slightly closer together than the rear. In this example, we measured 81 and 3/4 inches at the back and 81 and 3/8 inches at the front. To adjust, simply turn the tie rods until the desired toe-in is achieved.
• Secure the Steering Wheel: Before making adjustments to the drag link or tie rods, ensure your steering wheel is straight. You can run a seatbelt through the steering wheel to keep it from moving while you work underneath.
• Adjust the Jam Nuts: Once the measurements are set, tighten the jam nuts to secure everything in place. This temporary alignment should suffice until you can get a professional alignment done.

Final Checks and Considerations After Finishing Your Alignment

After completing your toe-in alignment, double-check all measurements to ensure they are within the desired range. This should be a good way to keep your rig aligned until the next time you're able to get to the shop and have it professionally worked - remember, this method is a quick fix for off-road rigs or temporary use; driving with misaligned wheels on the road can lead to faster tire wear and reduced handling, which is a no go especially if safety is your main priority, which it should be.
